Aver PTC310UN Dubai



Aver PTC310UN AI Dubai

Aver PTC310UN Al Dubai combine the 12X Optical Zoom lens and 4K resolution with hybrid auto tracking and smooth PTZ functions for broadcasting, streaming, or recording. Also equipped is Sony sensor that maintains a truly impressive video performance through every frame of your production.

Description

Aver PTC310UN AI Dubai

Aver PTC310UN AI Dubai makes powerful and reliable Pro AV capability available to everyone. Drawing inspiration from the AVer Professional PTZ Camera family, the PTC310UN features in-house AI functions like Presenter Mode and Zone Mode auto tracking, thanks to Human Detection processing. It combines the 12X Optical Zoom lens and 4K resolution with hybrid auto tracking and smooth PTZ functions for broadcasting, streaming, or recording. The PTC310UN is equipped with 4K resolution providing 4K Output Resolution with ultra-precise auto tracking. The PTC310UN also features a Sony sensor that maintains a truly impressive video performance through every frame of your production. The camera is equipped with 12X Optical Zoom camera reaches an incredible zoom 24X also with 2X Sensor Zoom. Interestingly, it works even while the camera is panning and tilting, allowing you to highlight content and rapidly change shooting angles. Operate a closer and clearer video feed with the unbeatable PTZ performance of the Aver PTC310UN AI Dubai. Human Detection AI Welcome AVer’s most advanced AI tool for Human Detection. This highly accurate processing function enables PTC310UN to easily detect and capture human forms and moving objects in seconds without missing targets. Also you can redirect focus in an instant with the PTC310UN by simply clicking on a target to quickly adjust the shooting angle and initiate precise tracking. This advanced feature is easy for anyone to operate via both remote control and intuitive Web UI. Track your target everywhere with Presenter Mode allowing  presenters to have flexibility to leave the stage and interact with the audience, all while being continuously tracked. The camera stays locked on its target, even if other people or objects get in the way. Zone Mode enhances your ability to capture content on multiple displays. Create up to four content zones to steadily capture the content on display rather than the presenter’s movements.

Key Features:

  • Full NDI®|HX for Greater Reach
    • The Aver PTC310UN Al Dubai complies with the most rigorous NDI standards to deliver the lowest latency for on-air camera control, switching, and streaming – all via IP connection. It makes live broadcasts faster and simpler, allowing users to stream for larger audiences without complicated and expensive equipment. Aver PTC310UN Al  is therefore, very efficient and flexible IP workflows.
  • 4K Output Resolution
    • Aver PTC310UN Al  is equipped with 4K resolution to  provide ultra-precise auto tracking. The PTC310UN also features a Sony sensor that maintains a truly impressive video performance through every frame of your production.
  • 12X Optical Zoom & 2X Sensor Zoom
    • The zoom power of Aver PTC310UN Al Dubai camera reaches an incredible 24X (12X optical and 2X sensor zoom). It works even while the camera is panning and tilting, allowing you to highlight content and rapidly change shooting angles. Operate a closer and clearer video feed with the unbeatable PTZ performance of the PTC310UN.
  • Human Detection AI
    •  Aver PTC310UN Al  boast of an advance Human Al detector. The highly accurate processing function enables PTC310UN to easily detect and capture human forms and moving objects in seconds. The technology captures fluid actions ensuring no details are missed during streaming.
  • Click & Track
    • Aver PTC310UN Al is capable of redirecting focus in an instant. Simply click on a target to quickly adjust the shooting angle and initiate precise tracking. Moreover, the advanced feature is easy for anyone to operate via remote control or Web UI.
  • Presenter Mode
    • It is possible with Aver PTC310UN Al to track your target everywhere with Presenter Mode. Presenters can therefore leave the stage with a lot of flexibility to leave the stage and interact with the audience, all while being continuously tracked. The camera stays locked on its target, even if other people or objects get in the way.
  • Zone Mode
    • Aver PTC310UN Al’s Zone Mode enhances your ability to capture content on multiple displays. Making it easy to create up to four Content Zones to steadily capture the content on display rather than the presenter’s movements.

Aver PTC310UN Al Dubai Specifications

  • Camera
  • Image Sensor
    • 1/2.8″ 4K Exmor CMOS
  • Effective Picture Elements
    • 8 Megapixels
  • Output Resolutions
    • 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/50, 720p/60, 720p/59.94, 720p/50
  • Minimum Illumination
    • 0.4 lux (IRE50, F1.6, 30fps)
  • S/N Ratio
    • ≥ 50dB
  • Gain
    • Auto, Manual
  • TV Line
    • 1400 (Center)
  • Shutter Speed
    • 1/1 to 1/32,000 sec
  • Exposure Control
    • Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
  • White Balance
    • Auto, Manual
  • Optical Zoom
    • 12X
  • Digital Zoom
    • 12X
  • Sensor Zoom
    • 2X
  • Viewing Angles
    • DFOV : 78° (Wide) to 7° (Tele)
    • HFOV : 70° (Wide) to 6° (Tele)
    • VFOV : 42° (Wide) to 3° (Tele)
  • Focal length
    • f = 3.9 mm (Wide) to 46.8 mm (Tele)
  • Aperture (Iris)
    • F = 1.6 (Wide) to 2.8 (Tele)
  • Minimum Working Distance
    • 0.3 m (Wide), 1.5m (Tele)
  • Pan/Tilt Angles
    • Pan : ±170°, Tilt : +90° / -30°
  • Pan/Tilt Speed (Manual)
    • Pan : 0.1° to 100° /sec, Tilt : 0.1° to 100° /sec
  • Preset Speed
    • Pan : 200° /sec, Tilt : 200° /sec
  • Preset Positions
    • 10 (IR), 256 (RS-232)
  • Camera Control – Interfaces
    • RS-232 (DIN8), RS-422 (RJ45), IP
  • Camera Control – Protocols
    • VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP)
  • Image Processing
    • Noise Reduction (2D / 3D), Flip, Mirror
  • Power Frequencies
    • 50Hz, 60Hz
  • AI Auto Tracking Functions
  • Tracking Modes
    • Presenter Mode, Zone Mode
  • Audio
  • Channels
    • 2ch (Stereo)
  • Codecs
    • AAC-LC (48 / 44.1 / 32 / 24K), G.711, PCM (8K)
  • Sample Rates
    • 48 / 44.1 / 32 / 24 / 16 / 8 KHz
  • Interface
  • Video Outputs
    • 3G-SDI, HDMI, IP, USB
  • Audio Outputs
    • 3G-SDI, HDMI, IP, USB
  • Audio Inputs
    • MIC / Line in
  • General
  • Power Requirement
    • AC100V-AC240V to DC12V/5A
  • Power Consumption
    • 18W
  • PoE
    • PoE+
  • Dimensions (W x H x D)
    • 180.0 x 183.5 x 145.0 mm
  • Net Weight
    • 1.7 (±0.1) kg
  • Application
    • Indoor
  • Tally Lamp
    • Yes
  • Security
    • Kensington slot
  • Remote Control
    • Infrared
  • Operating Conditions
    • Temperature: 0°C to +40°C ; Humidity: 20% to 80%
  • Storage Conditions
    • Temperature: -20°C to +60°C ; Humidity: 20% to 95%
  • IP Streaming
  • Resolution
    • 4K 30fps
  • Network Video Compress Format
    • H.264, H.265, MJPEG
  • Maximum Frame Rate
    • 4K 30fps or 1080p 60fps
  • Bit-rate Control Modes
    • VBR, CBR (selectable)
  • Range of Bit-Rate Setting
    • 512 Kbps to 32 Mbps
  • Network Interface
    • 10/100/1000 Base-T
  • Multi-Stream Capability
    • 2 (RTSP / Web Page), 1080p 60fps (max.)
  • Network Protocols
    • IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
  • NDI®|HX Capability
    • Yes (NDI HX2)
  • USB
  • Connector
    • USB 3.0
  • Video Formats
    • MJPEG, YUY2
  • Maximum Video Resolution
    • 2160p
  • USB Video Class
    • UVC1.1
  • USB Audio Class
    • UAC1.0
  • Web UI
  • Live Video Preview
    • Yes
  • Camera PTZ Control
    • Pan, Tilt, Zoom, Focus, Preset Control
  • Camera/Image Adjustment
    • Exposure, White Balance, Picture
  • Network Configuration
    • DHCP, IP Address, Gateway, Subnet Mask, DNS
  • Software Tools
  • IP Search & Configuration Tool
    • Support Windows® 7 or later
  • PTZ Management
    • Support Windows® 7 or later
  • PTZ Control Panel
    • Support iPadOS® v11 or later
  • CaptureShare
    • Support Windows® 7 or later
  • Warranty
  • Camera
    • 3 Years
  • Accessories
    • 1 Year
