Description
Cisco Catalyst3850-48S Network Switch Dubai
The Cisco Catalyst3850-48S Dubai Switch provides capabilities that ideally suited to support the convergence of wired and wireless access. The new Cisco Unified Access Data Plane (UADP) Application-Specific Integrated Circuit (ASIC) powers the switch and enables uniform wired-wireless policy enforcement, application visibility, flexibility, and application optimization. This convergence is built on the resilience of the new and improved Cisco StackWise-480 technology.
The Cisco Catalyst3850-48S Dubai supports full IEEE 802.3at Power over Ethernet Plus (PoE+), Cisco Universal Power Over Ethernet (Cisco UPOE), modular and field-replaceable network modules, RJ-45 and fiber-based downlink interfaces, and redundant fans and power supplies.
Features
- The Cisco Catalyst3850-48S Dubai is integrated wireless controller capability with support for up to 100 access points and 2000 wireless clients on each switching entity (switch or stack)
- 48 10/100/1000 Ethernet PoE+ [800W] ports with Energy-Efficient Ethernet (EEE)
- Cisco StackWise-480 technology provides scalability and resiliency with 480 Gbps of stack throughput
- Cisco StackPower technology provides power stacking among stack members for power redundancy
- Cisco Catalyst3850-48S Dubai boasts of a full IEEE 802.3at (PoE+) with 30W power on all copper ports in 1 Rack Unit (RU) form factor
- 715WAC power supply 1 RU
- IEEE 802.3bz (2.5/5 G/s BASE-T) to go beyond 1 Gb/s with existing Cat5e and Cat6
- IEEE 802.1ba AV Bridging (AVB) built-in to provide better AV experience for including improved time synchronization and QoS
- Software support for IPv4 and IPv6 routing, multicast routing, modular Quality of Service (QoS), Flexible NetFlow (FNF), and enhanced security features
- Single universal Cisco IOS Software image across all license levels, providing an easy upgrade path for software features
- Cisco DNA services delivered through Cisco ONE Software, providing simplified, high-value solutions with license portability and flexibility
- Cisco Catalyst3850-48S Dubai comes with built-in support for AES-256 with the powerful MACSEC 256-bit for SFP+ and Multigigabit models and 128-bit encryption algorithm available on all models
- Enhanced Limited Lifetime Warranty (E-LLW) with Next Business Day (NBD) advance hardware replacement and 90-day access to Cisco Technical Assistance Center (TAC) support
Technical Specs
| Product Code | WS-C3850-48XS-S |
| Enclosure Type | 1 RU |
| Feature Set | IP Base |
| Ports | 48 x 10/100/1000 10G SFP+ Optical ports |
| Maximum stacking number | 9 |
| Stack bandwidth | 480 Gbps |
| Switching Capacity | 1280 Gbps |
| RAM | 8 GB |
| Flash Memory | 8 GB |
| Dimensions | 4.45 X 44.5 x 51.1 cm |
