Description

Grandstream GXP1615  VoIP Phone Overview

Grandstream GXP1615 delivers a user-friendly VoIP calling experience in a lower cost range compared to competitors. The GXP1 615 is a feature-rich small business IP Phone that has been designed to meet the demands for a 1-line phone with integrated PoE. Along with its amazing looks, these telephones features duplex speakerphone with HD audio. GXP1 615 is an astonishing phone that saves your money as well as offer clear communication. The Grandstream GXP 1615 IP Phone has a 132 x 48 inch LCD screen for easy viewing, with 3 XML programmable softkeys that allow for easy customization. Grandstream GXP1615 features state-of-the-art security encryption technology( SRTP and TLS) and supports a variety of automated provisioning options.

The GXP1615 is a reliable Basic IP phone for the user who reԛuires standard features for a light to medium call volume. Stay in touch with others with its 2 lines/SIP accounts, enjoy crystal clear HD audio and utilize its dual-switched 10/100 mbps ports with integrated PoE. Maximize your productivity with essential supported features such as 3-way conferencing and 3 XML programmable soft keys. Together, these features make the GXP1615 an easy-to-use and effective Basic IP phone.

GXP1615 Features

• PoE Supported
• Single SIP account, up to 2 call appearances, 3 XML programmable context-sensitive soft keys, 3-way conferencing, multi-language support
• Personalized music ring tone/ ring back tone and integration with advanced Web and enterprise applications, local weather service
• Gigabit Ethernet
• Dual-switched 10/100/ 1000 Mbps ports
• Use with Grandstream’s UCM6100 series and UCM6200 IP PBX appliance for Zero-Config provisioning, 1-touch call recording and more
• Full-duplex hands-free speakerphone with advanced acoustic echo cancellation, Electronic Hook Switch( EHS) with Plantronics headsets
• Automated provisioning utilizing TR-069 or encrypted XML configuration file, SRTP and TLS for advanced security protection, 802.1 x for media access control
• 132 x 48 pixel LCD display
• Large phonebook( up to 500 contacts) and call history( up to 200 records )

GXP1615 Complete Specification

• Protocols/ Criteria: SIP RFC3 261, TCP/ IP/ UDP, RTP/ RTCP, HTTP/ HTTPS, ARP/ RARP, ICMP, DNS( A record, SRV, NAPTR ), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1 x, TLS, SRTP
• Network Interfaces: Dual switched auto-sensing 10/100 Mbps Ethernet ports
• Graphics Display: 132 x 48 LCD display
• Feature Keys: 2 line keys with dual-color LED and 1 SIP account, 3 XML programmable context-sensitive soft keys, 5( navigation, menu) keys. 13 dedicated function keys for PAGE/ INTERCOM, PHONEBOOK, MESSAGE, HOME, HOLD, RECORD, MUTE, HEADSET, TRANSFER, CONFERENCE, SEND and REDIAL, SPEAKERPHONE, VOLUME
• Voice Codecs: Subsistence for G. 711 m/ a, G. 723, G. 726-32, G. 729 A/ B, iLBC( pending ), Opus( pending ), in-band and out-of-band DTMF( In audio, RFC2 833, SIP INFO )
• Telephony Features: Hold, transfer, forward( unconditional/ no-answer/ busy ), 3-way conferencing, call park/ pickup, downloadable phone book( XML, LDAP, up to 500 items ), call waiting, call history( up to 200 records ), off-hook automobile dial, auto answer, click-to-dial, flexible dial scheme, hot desking, personalized music ringtones, server redundancy& fail-over
• Headset Jack: RJ9 headset jack( letting EHS with Plantronics headsets )
• Base Stand: Yes, 2 angled positions available, wall mountable
• Wall Mountable: Yes
• Layer 2 QoS (8 02.1 Q, 802.1 P) and Layer 3( ToS, DiffServ, MPLS) QoS
• QoS: Layer 2 QoS (8 02.1 Q, 802.1 P) and Layer 3( ToS, DiffServ, MPLS) QoS
• Security: User and administrator level access control, MD5 and MD5-sess based authentication, 256 -bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1 x media access control
• Multi-language: English, German, Italian, French, Spanish, Portuguese, Russian, Croatian, simplified and traditional Chinese, Korean, Japanese and more
• Upgrade/ Provisioning: Firmware upgrade via TFTP/ HTTP/ HTTPS, mass provisioning employing TR-069 or AES encrypted XML configuration file
• Power& Green Energy Efficiency: Universal Power Supply Input 100-240 VAC 50-60 Hz; Output +5 VDC, 600 mA
• Physical: Dimension: 209 mm( L) x 184.5 mm( W) x 76.2 mm( H)( with handset) Unit weight: 0.74 kg; Package weight: 1.1 k
• Temperature and Humidity: Operation: 0degC to 40 degC, Storage: -10 deg to 60 degC, Humidity: 10% to 90% Non-condensing
