Hanwha TNB-6030 CCTV Camera
The Hanwha TNB-6030 CCTV Camera, previously recognized as Samsung CCTV, is a high-performance box camera designed for professional surveillance applications. With Full HD resolution, intelligent video analytics, and cybersecurity features, this camera delivers high-quality monitoring and enhanced security.
Full HD High-Resolution Imaging
The Hanwha TNB-6030 is equipped with a 2MP Full HD sensor, delivering clear and sharp video quality, making it suitable for detailed monitoring and forensic-level security applications.
AI-Powered Intelligent Analytics
Built-in AI-based analytics enable object detection, motion detection, loitering alerts, and virtual line crossing. These features enhance situational awareness and provide real-time threat detection, reducing false alarms.
H.265 Video Compression for Efficiency
Using H.265 compression technology, the TNB-6030 optimizes bandwidth and storage usage while maintaining high-quality video output, ensuring cost-effective long-term video retention.
Robust Cybersecurity Features
Hanwha’s proprietary security technology protects the TNB-6030 from cyber threats, ensuring encrypted video transmission and secure authentication to prevent unauthorized access.
Easy Integration and Installation
Supporting Power over Ethernet (PoE), the TNB-6030 simplifies installation by reducing cabling needs. It is ONVIF-compliant, enabling seamless integration with leading video management systems (VMS) for efficient security operations.
Key Specifications:
- Resolution: 2MP Full HD (1920 × 1080)
- AI-powered analytics: Motion detection, loitering alerts, virtual line crossing, object classification
- Video compression: H.265/H.264/MJPEG
- Cybersecurity: Secure encryption and authentication
- Lens compatibility: C/CS mount (various lens options available)
- Power source: Power over Ethernet (PoE) and 12V DC
- Operating temperature: -10°C to +50°C (14°F to 122°F)
- Network connectivity: Ethernet 10/100/1000 Base-T
- ONVIF compliance: Compatible with major VMS platforms
Specifications:
| Make | Hanwha Vision |
| Manufacturer | Hanwha Vision Europe (formerly Hanwha Techwin Europe) |
| Category | CCTV>IP cameras |
| Model code | TNB-6030 |
| Series | WISENET T SERIES |
| Chip Inch Size | 1/2.8 inch |
| Colour Type | True Day / Night |
| Resolution | 2MP resolution |
| Digital (DSP) | Yes |
| Specialist Type | Network |
| Sensitivity Lux | 0.06 |
| Auto Iris | Yes |
| Electrical Specifications | Voltage: 12 V DC, PoE Power Consumption: 6 W |
| Focal Length mm | 4.6 |
| Wide Dynamic Range | Yes |
| Picture Elements HxV | 1945 x 1109 |
| Network Properties | Image Frame Rate: 30 ~ 60 fps Interface: RJ-45 (10/100 BASE-T) Network Protocols: TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP,RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour |
