Hanwha TNO-6010M Thermal CCTV Camera offers advanced thermal detection, rugged IP66-rated housing, intelligent analytics, and optimized H.265 video compression. Its compact form factor makes it ideal for space-sensitive installations without compromising on performance.

Description

Hanwha TNO-6010M Thermal CCTV Camera

The Hanwha TNO-6010M Thermal CCTV Camera, previously recognized as Samsung CCTV, is a compact yet powerful thermal surveillance solution designed for perimeter security, industrial monitoring, and critical infrastructure protection. Engineered for reliable thermal imaging in complete darkness, fog, smoke, and extreme weather conditions, this camera ensures accurate detection and monitoring.

High-Performance Thermal Imaging

The Hanwha TNO-6010M is equipped with an advanced thermal imaging sensor that captures precise heat signatures, ensuring continuous surveillance even in zero-light conditions and challenging environments where conventional cameras may struggle.

Compact and Rugged Design

With a compact form factor, the TNO-6010M is ideal for discreet yet robust surveillance applications. It features an IP66 weatherproof and IK10 vandal-resistant enclosure, ensuring durability in outdoor and high-risk environments.

Intelligent Video Analytics

The camera integrates AI-driven intelligent analytics, including motion detection, intrusion detection, virtual line crossing, and tampering alerts. These features improve situational awareness and enable real-time response to security threats.

Efficient Bandwidth and Storage Management

Utilizing H.265 video compression technology, the TNO-6010M reduces bandwidth and storage usage while maintaining high-quality thermal imaging. This ensures longer recording durations and efficient video data management.

Easy Installation and Seamless Integration

Supporting Power over Ethernet (PoE), the Hanwha TNO-6010M simplifies installation with a single cable for both power and data transmission. It is fully ONVIF-compliant, enabling seamless integration with major video management systems (VMS).

Key Specifications:

  • Thermal imaging resolution: VGA (640×480)
  • Accurate detection in darkness, fog, smoke, and harsh weather
  • Fixed thermal lens with multiple focal length options
  • Compact IP66 weatherproof and IK10 vandal-resistant housing
  • AI-powered analytics: Motion detection, intrusion detection, virtual line crossing, tampering alerts
  • Video compression: H.265/H.264/MJPEG
  • Power source: Power over Ethernet (PoE)
  • Operating temperature: -40°C to +60°C (-40°F to +140°F)
  • Network connectivity: Ethernet 10/100 Base-T
  • ONVIF compliant: Integrates with major VMS platforms

Specifications:

Video
Imaging Device 1/2.8″ 2MP CMOS
Effective Pixels 1945(H)x1097(V)
NETD None
Pixel Size None
Min. Illumination COLOR 0.04lux(F2.0, 1/30sec) B/W 0.004lux(F2.0, 1/30sec)
Video Out CVBS : 1.0 Vpp / 75Ω composite, 720 x 480(N), 720 x 576(P), for installation USB : micro USB type B, 1280 x 720 for installation
Lens
Focal Length (Zoom Ratio) 2.8mm fixed focal
Max. Aperture Ratio F2.0
Angular Field of View H: 113.7˚ / V: 61.5˚ / D: 134.5˚
Min. Object Distance 0.4m(1.31ft)
Focus Control Manual
Lens Type Fixed
Mount Type Board-in Type
Optional Lens None
Operational
IR Viewable Length None
Camera Title Displayed up to 85 characters
Day & Night Auto(ICR)
Backlight Compensation BLC, HLC, SSDR
Wide Dynamic Range 150dB
Digital Noise Reduction SSNRⅤ
Digital Image Stabilization Support(built-in gyro sensor)
Defog Support
Motion Detection 8ea, 8point polygonal zones
Privacy Masking 32ea, polygonal zones – Color: Grey/Green/Red/Blue/Black/White – Mosaic
Gain Control Low / Middle / High
White Balance ATW / AWC / Manual / Indoor / Outdoor
LDC Support
Electronic Shutter Speed Minimum / Maximum / Anti flicker(2~1/12,000sec)
Video Rotation Flip, Mirror, Hallway view
Analytics Defocus detection, Directional detection, Fog detection, Face detection, Motion detection, Digital auto tracking, Appear/Disappear, Enter/Exit, Loitering, Tampering, Virtual line, Shock detection
Business Intelligence People counting, Queue management, Heatmap
Serial Interface None
Alarm I/O None
Alarm Triggers Analytics, Network disconnect
Alarm Events File upload via FTP and e-mail Notification via e-mail SD/SDHC/SDXC or NAS recording at event triggers
Network
Ethernet M12
Video Compression H.265/H.264: Main/Baseline/High MJPEG
Resolution 1920×1080, 1280×1024, 1280×960, 1280×720, 1024×768, 800×600, 800×448, 720×576, 720×480, 640×480, 640×360, 320×240
Max. Framerate H.265/H.264: Max. 60fps MJPEG: Max. 30fps
Smart Codec WiseStreamⅡ
Bitrate Control H.265/H.264: CBR or VBR MJPEG: VBR
Streaming Multiple streaming(Up to 10 profiles)
Audio Compression None
Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour
Security HTTPS(SSL) Login Authentication Digest Login Authentication IP Address Filtering User access log 802.1X Authentication(EAP-TLS, EAP-LEAP)
Edge Storage Micro SD/SDHC/SDXC 1slot 256GB
Application Programming Interface ONVIF Profile S/G/T SUNAPI(HTTP API) Wisenet open platform
Web Viewer Supported OS: Windows 7, 8.1, 10, Mac OS X 10.10, 10.11, 10.12 Recommended Browser: Google Chrome Supported Browser: MS Explore11, MS Edge, Mozilla Firefox(Window 64bit only), Apple Safari(Mac OS X only)
Memory 1024MB RAM, 256MB Flash
Environmental
Operating Temperature / Humidity -30°C ~ +55°C(-22°F ~ +131°F) / Less than 90% RH
Storage Temperature / Humidity -50°C ~ +60°C(-58°F ~ +140°F) / Less than 90% RH
Certification UL, IP66, NEMA 4X, IK10 EN50581:2012, EN55011:2009+A1:2010(EN50121-3-2:2015), EN61000-4-2:2009, EN61000-4-3:2006+A2:2010, EN61000-4-4:2012, EN61000-4-5:2014, EN61000-4-6:2009, EN50155:2007, EN-45545-2, NFPA 130, BSS 7239
Electrical
Input Voltage M12 with PoE(IEEE802.3af, Class3)
Power Consumption 8W(Max), 4.3W(Typ)
Mechanical
Color / Material Black / Aluminum (Hood : Silicone rubber)
RAL Code RAL9005
Product dimensions / weight Φ62 x 372mm(w/o Hood), 1170g(2.58 lb)
