Description
Huawei S380-H8T3ST Multi-Service Gateway Dubai
The Huawei S380-H8T3ST Dubai Multi-Service Gateways are cutting-edge devices that seamlessly integrate routing, switching, and wireless access control (WAC) into one comprehensive unit. These advanced gateways are available in a range of configurations, each designed to meet a broad spectrum of network requirements. The models offer either 4 or 8 downlink GE electrical ports, with the flexibility to choose between PoE (Power over Ethernet) and non-PoE options, allowing users to select the configuration that best suits their specific needs. Additionally, certain models come equipped with GE uplink ports, further enhancing network flexibility and overall performance.
Engineered for ease of use, the Huawei S380-H8T3ST Dubai Multi-Service Gateways support flexible Ethernet networking, significantly streamlining the installation and deployment process. This user-centric design makes them an ideal choice for a wide variety of indoor coverage applications. These gateways are especially well-suited for small and medium-sized enterprises (SMEs), including small office/home office (SOHO) environments, cost-conscious hotels, manufacturing facilities, primary and secondary educational institutions, and building security systems. Their exceptional versatility and adaptability ensure that the Huawei S380-H8T3ST Dubai can effectively meet the diverse networking needs of various business sectors, delivering efficient and reliable performance across numerous applications.
Furthermore, the Huawei S380-H8T3ST gateways are designed with scalability in mind, ensuring that as businesses grow and their networking demands evolve, these gateways can be easily upgraded and expanded to accommodate such changes. The integration of advanced security features provides robust protection against potential threats, safeguarding the network’s integrity and confidentiality. This combination of features makes the Huawei S380-H8T3ST Dubai Multi-Service Gateways an ideal solution for businesses in search of a reliable, high-performance networking device capable of adapting to their changing needs. With these gateways, businesses can confidently expand their network infrastructure, knowing they have a dependable and versatile solution to support their growth and operational efficiency.
Technical Specifications
| Description | S380-H8T3ST, 2*GE WAN, 1*GE(SFP) WAN, 8*GE LAN |
| Part Number | 98012181 |
| Model | S380-H8T3ST |
| First supported version | V600R022C10 |
| Dimensions without packaging (H x W x D) [mm(in.)] | Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 442.0 mm x 160.0 mm (1.72 in. x 17.4 in. x 6.3 in.)
Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 442.0 mm x 166.7 mm (1.72 in. x 17.4 in. x 6.56 in.) |
| Dimensions with packaging (H x W x D) [mm(in.)] | 90.0 mm x 550.0 mm x 260.0 mm (3.54 in. x 21.65 in. x 10.24 in.) |
| Chassis height [U] | 1 U |
| Chassis material | Metal |
| Weight without packaging [kg(lb)] | 1.6 kg (3.53 lb) |
| Weight with packaging [kg(lb)] | 2.1 kg (4.63 lb) |
| Typical power consumption [W] | 11.25 W |
| Typical heat dissipation [BTU/hour] | 38.4 BTU/hour |
| Maximum power consumption [W] | 11.5 W |
| Maximum heat dissipation [BTU/hour] | 39.2 BTU/hour |
| Static power consumption | 6.49 |
| MTBF [years] | 63.71 years |
| MTTR [hours] | 2 hours |
| Availability | > 0.99999 |
| Noise at normal temperature (acoustic power) [dB(A)] | Noise-free (no fans), < 30 |
| Noise at normal temperature (acoustic pressure) [dB(A)] | Noise-free (no fans), < 20 |
| Number of card slots | 0 |
| Number of power slots | 0 |
| Number of fans modules | 0 |
| Switching capacity | To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel. |
| Packet forwarding rate | To obtain data of this specification item, see the corresponding datasheet or contact the product sales personnel. |
| WAN ports | 2 x GE WAN, 1 x GE (SFP) WAN |
| LAN ports | 8 x GE LAN |
| Redundant power supply | Not supported |
| Long-term operating temperature [°C(°F)] | 0°C to 40°C (32°F to 104°F) at an altitude of 0-1800 m (0-5906 ft.) |
| Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800-5000 m (5906-16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
