Description

Polycom Studio in Detail

The Poly Studio video bar delivers clear, high-fidelity stereo audio covering up to 12 feet/3.6 meters. It features a dynamic video experience with a wide 120-degree field of view, a 4K-resolution sensor with 5x electric zoom, and unique speaker tracking and group framing technology.

PolyStudio is compact technology built to bring your Microsoft Teams meeting participants together for great discussions. Every participant in the room is clearly visible on the monitor regardless of their distance from the unit, thanks to its Ultra High Definition 2160p camera with 4K capture resolution and an amazing 120° Field of View. Using it’s two technologically advanced cameras, PolyStudio is able to zoom in 5x/EPTZ while framing and tracking the speaker’s voice.

The PolyStudio is configured for small conference rooms. The inbuilt Acoustic Fence technique helps the device filter surrounding noise from interrupting your calls, ensuring you enjoy a smooth meeting experience.

Polycom Studio Audio

The Polycom Studio comes with stereo speakers with a frequency response ranging between 100Hz and 20KHz. The output is an impressive 90dB at 0.5 m range, ensuring every participant is heard clearly and audibly. Its Poly Acoustic Clarity Technology offers full-duplex conversations, acoustic echo cancellation, and background noise suppression to give you extreme performance and sensitivity while maintaining crystal clear sound.

The unit comes with mute/unmute options that are controlled from the supplied remote by pressing a single button from whatever angle or corner of the conference room.

Polycom Studio Auto Framing & Speaker Tracking

Polycom Studio features unique automatic camera framing and tracking technology. The Auto Framing enable The Polycom Studio USB video bar automatically frames the participants in the room. The Studio USB Meeting bar automatically frames all the people in the meeting. This is a dynamic technology, so if someone enters or leaves, the camera automatically frames the new group.

Using the six-microphone array, Studio can track who is actively speaking. It then zooms in on that person, so you can better see their body language. You don’t have to adjust the cameras when starting a meeting. In Speaker Tracking Mode Poly Studio USB video bar zooms in on an active speaker without the use of remote control or camera presets.

Poly Studio Supplier Dubai

Poly Studio Acoustic Fence Technology

Poly Studio Equipped with Accousted Fence technology. Acoustic Fence continuously explores the differences in sound between multiple microphones to find who is the main talker, and then selects, combines, and mutes the remaining ones to do the most targeted job of sending just the main talker’s conversation to the far-end listener.  The resulting impact is that the listener hears the talker without interruption; any background sounds are heard just in snippets that don’t connect to make another distracting dialog.  Background sounds and talking are sliced and blanked by the cadences of your own speaking, rendering your voice clear to the far end and nearby conversations incomprehensible.

Poly combines Acoustic Fence with the natural performance of low-noise directional microphones and some very clever acoustic designs to deliver the most effective performance of your Video Conferencing Room.

Polycom Studio Compatibility

Polycom Studio works perfectly with any application that supports standard USB audio and video drivers including Zoom Certified, LogMeIn GoToMeeting®, BlueJeans Network, Amazon Chime, Cisco WebEx®,  VidyoDesktop™, Polycom RealPresence Desktop, and Google Hangouts™ platforms. It is also Certified for Microsoft Teams and Skype for Business.

Expand Your Room With Expansion Mics

Extend the reach of your Polycom Studio USB Video Bar or Polycom RealPresence Debut with this expansion microphone. The three-microphone array gives you 360° coverage with the rich HD audio you expect from Polycom. This wired microphone comes with a 25-ft cable.

Best ion Class for Microsoft Teams Meeting Rooms

Poly Studio makes collaboration easy for you. Polycom’s long-term partnership with Microsoft to ensure you can achieve more. Ranging from small huddle rooms to large conference rooms our solutions transform collaboration bringing a consistent, first-class audio and video experience to your meeting rooms. Get the best out of Microsoft Teams Rooms With Poly Studio VideoConferencing.

Poly Studio Dubai Uae

PRODUCT SPECIFICATIONS

DIMENSIONS

• Unit dimensions :
  • 105mm × 700mm × 700mm = 4.2″ × 27.3″ × 2.8″ (H×W×D) without stand
  • 156mm × 700mm × 70mm = 6.2″ × 27.3″ × 2.8″ (H×W×D) with stand
• Weight :
  • 5lbs 2.6oz (2342g) without stand
  • 6lbs 4.7oz (2856g) with stand
• Remote control dimensions:
  • 183mm × 40mm × 19mm = 7.2″ ×1.6″ × 75″. (W×H×D)
• Camera:
  • 120° Fov
  • UHD 2160p (4K) capture resolution
  • Automatic people framing & Speaker tracking
  • 5× zoom/ EPTZ
  • 2 camera presets
• Audio:
  • Poly Acoustic Clarity technology provides full – duplex conversations, acoustic echo cancellation and background noise suppression
  • Poly NoiseBlock Technology
  • Poly Acoustic Fence technology
  • Mute/unmute controls
  • Stereo microphones: 6 – element beamforming microphone array,12ft pickup range, 120Hz – 16kHz frequency response
  • Stereo speakers: 100Hz – 20kHz frequency response, output – 90 dB @ 0.5m
• Interfaces
  • 1× USB 3.0 Type C port (with 2.0 compatibility)
  • Power connector
  • Optional external microphone
  • 5mm stereo Audio In
  • Kensington security lock
  • 110 a.c Wi -Fi wireless networking for manageability; IEEE 802.11a/b/g/n compatible
  • Bluetooth® 4.2
• Application compatibility
  • Compatible with any application that supports standard USB audio and video drivers, including but not limited to:
    1. Certified for Microsoft Teams and Skype for Business
    2. Zoom certified

• LogMeIn GoToMeeting®

1. BlueJeans Network
2. Google Hangouts™ communication platform
3. Amazon Chime

• Cisco WebEx®
• VidyoDesktop™

1. Polycom RealPresence Desktop

• Security
  • 1× support
  • Certification management
• Manageability (via WiFi)
  • Polycom Companion App(running on Win/Mac PC connected to device)
  • Polycom RealPresence Resource Manager
  • Polycom Device Management Service
• Environmental
  • Operating Temperature: 32° – 104° F (0-40°C)
  • Relative humidity – 5-95%, non condensing
  • Storage temperature: 13 -160 °F (-25 – 70°C)
• Application Requirements
  • Supported operating systems
    8. Windows 7,8.1,10
    9. MacOS 10.12, 10.13, 10.14
  • Support for standard audio and video device drivers
    1. UAC 1.0 Audio
    2. UVC 1.1/1.5 Video

• HID 1.11

• Power Requirements
  • 12VDC/5A @ 100~ 240VAC, 50/60Hz

Package Contents

• PolyStudio
• Remote control with 2AAA batteries
• Power adapter
• 5m USB 2.0 cable (Type – C to Type – A)
• Wall mount kit
• Setup sheet

Optional Accessories

• Expansion microphone
• Display mount

Warranty Information

PolyStudio comes with a 1 year Studio limited hardware Warranty
