Ruijie RG-ES105GD Network Switch Dubai is a Real-easy cost-effective unmanaged access switch with metal casing designed for SMEs. The RG-ES100 Series supports plug-and-play without requiring any configuration

Description

Ruijie RG-ES105GD Network Switch Dubai

Ruijie RG-ES105GD Network Switch Dubai is a Real-easy cost-effective unmanaged access switch with metal casing designed for SMEs. The RG-ES100 Series supports plug-and-play without requiring any configuration, which can meet the requirements of various scenarios such as wired, wireless and surveillance networks. RG-ES100 Series can be used to access the networks, cameras, and video intercom systems in campuses, equipment rooms, factories, office buildings, residential areas, parking lots, and other video surveillance environments

Features

  • Metal Casing
  • The entire casing is made of metal which provides better heat dissipation.
  • Easy to Install
  • The compact size allows easy installation in the ELV box at home or the waterproof surveillance junction box, as it only takes up little space.
  • Enterprise-grade Quality
  • The high-quality 8-core network cable and enterprise-grade components ensure no packet loss or lagging for data transmission.

Plug and Play

Ruijie RG-ES105GD Network Switch Dubai supports self-adaptive ports and plug-and-play feature with zero configuration.

Metal Casing

The Ruijie RG-ES105GD  has its entire casing made of metal which provides better heat dissipation.

Easy to Install

The compact size allows easy installation in the ELV box at home or the waterproof surveillance junction box, as it only takes up little space.

Enterprise-grade Quality

The Ruijie RG-ES105GD Network Switch features a high-quality 8-core network cable and enterprise-grade components ensure no packet loss or lagging for data transmission.

Technical Specifications

Model ES105GD
Ports 5 10/100/1000Mbps RJ45 ports
Maximum port forwarding rate 1000Mbps
AutoMDI/MDIX Support
MAC address 2K
Backplane bandwidth 10Gbps
Maximum packet forwarding rate 7.44Mpps
LED indicator
  • Link/Act status LED indicator for each port,
  • Power indicator
Dimensions 119mm*62mm*24mm
Power input / output External 5VDC 1.0A
Maximum power consumption ≤5W
Temperature
  • Operating temperature : 0 ℃ ~ 40 ℃
  • Storage temperature : -40 ℃ ~ 70 ℃
Humidity
  • Operating humidity : 10% ~ 90% non-condensing
  • Storage humidity : 5% ~ 90% non-condensing
